Finished (Heated and Cooled) Areas
Heated Area Main Floor | 1600 |
Heated Area Second Floor | 0 |
Total Finished Square Footage | 1600 |
Unfinished (unheated) Areas
Front Porch | 0 |
Rear Porch | 0 |
Other Porches | 86 |
Garage | 489 |
Storage | 39 |
Bonus Room | 0 |
Other | 0 |
Total Unfinished Square Footage | 614 |
Additional Plan Specs
Primary Roof Pitch | 10:12 |
Other Roof Pitches | 4:12 |
| Roof Peak Height | 22-6 |
-
1600 Sq Ft.
-
1
Story
-
3
Beds
-
2
Baths
-
68-0 Width
-
39-8 Depth
-
2 Car
Couldn't load pickup availability
Description
Description
Experience comfort and style with the Jaime House Plan. Its open layout features a stunning trayed ceiling and cozy gas logs in the great room, perfect for relaxing or entertaining. The kitchen’s raised bar and island peninsula create an inviting space for gatherings. The main suite is a true retreat, boasting a large whirlpool tub, separate shower, dual sinks, enclosed toilet, and a spacious walk-in closet. An oversized second bathroom with dual sinks adds convenience for the whole family. This plan offers everything you need for comfortable family living.
Below you will find a listing of the typical items found:
