Finished (Heated and Cooled) Areas
Heated Area Main Floor | 630 |
Heated Area Second Floor | 525 |
Total Finished Square Footage | 630 |
Unfinished (unheated) Areas
Front Porch | 90 |
Rear Porch | 0 |
Other Porches | 0 |
Garage | 1582 |
Storage | 230 |
Bonus Room | 0 |
Other | 0 |
Total Unfinished Square Footage | 1902 |
Additional Plan Specs
Primary Roof Pitch | 12:12 |
Other Roof Pitches | 3:12 |
| Roof Peak Height | 28-0 |
-
630 Sq Ft.
-
1
Story
-
1
Bed
-
1
Bath
-
51-0 Width
-
52-0 Depth
-
2 Car
Couldn't load pickup availability
Description
Description
Discover the perfect combination of style, function, and flexibility with this charming barn-style carriage house. Designed to accommodate an RV along with additional vehicle and storage space, this plan is ideal for homeowners who need room for their recreational gear, workshop, or hobbies. You'll also find a thoughtfully designed living space featuring a full kitchen, comfortable living area, private bedroom, and full bathroom—perfect for guests, extended family, a home office, or a rental opportunity.
