Finished (Heated and Cooled) Areas
Heated Area Main Floor | 1900 |
Heated Area Second Floor | 0 |
Total Finished Square Footage | 1900 |
Unfinished (unheated) Areas
Front Porch | 214 |
Rear Porch | 273 |
Other Porches | 0 |
Garage | 552 |
Storage | 29 |
Bonus Room | 325 |
Other | 0 |
Total Unfinished Square Footage | 1393 |
Additional Plan Specs
Primary Roof Pitch | 8:12 |
Other Roof Pitches | 14:12, 12:12, 3:12 |
River Trace House Plan
River Trace House Plan
SKU:1900-3
-
1900 Sq Ft.
-
1.5
Stories
-
3
Beds
-
2
Baths
-
62-6 Width
-
60-0 Depth
